CONE CRUSHERS.
Maximum Feed Size
-
- 365 mm
- 14 inches
Capacity
-
- Up to 3,000 mtph
- Up to 3,307 stph
Motor Power
-
- 132- 1,000 kW
- 150 – 1,350 hp
Discover the Power and Versatility of Our Cone Crushers.
The C & CM Series Cone Crushers are designed with a high pivot point and a large eccentric throw, leading to greater feed intake capacity and increased production. These crushers have high-grade alloy steel main frames, high load-bearing bronze bushes, and advanced hydraulic controls, resulting in a reliable machine that is safe and easy to operate and maintain.
Technical Parameter Table
Units:
Metric
| Model | Head Diameter (mm) | Max Feed Size (mm) | Motor Power (kW) | Capacity (mtph) |
|---|---|---|---|---|
| C35 | 889 | 170 | 132 – 160 | 85 – 300 |
| C40 | 1016 | 210 | 220 – 250 | 100 – 450 |
| C45 | 1143 | 235 | 315 | 150 – 600 |
| C50 | 1270 | 280 | 355 – 400 | 180 – 650 |
| C55 | 1445 | 300 | 450 | 220 – 850 |
| C65 | 1651 | 305 | 500 – 550 | 310 – 1000 |
| C75 | 1850 | 360 | 710 | 375 – 1500 |
| CM75 | 1905 | 330 | 550 – 630 | 400 – 1500 |
| CM80 | 2083 | 335 | 630 – 710 | 510 – 2300 |
| CM90 | 2337 | 365 | 750 – 1000 | 650 – 3000 |
